Provision-ISR NVR-4100 User Manual

2.2 Front Panel Descriptions Notice: The front panel descriptions are only for reference; please make the object as the standard. Front pa

2.3 Rear Panel Instructions The interfaces of the rear panels are for reference only. Fig 2-3 Rear Panel for 4-ch Item Name Description 1 Audio ou

2.4 Remote Controller It uses two AAA size batteries.  Open the battery cover of the Remote Controller.  Place batteries. Please take care of th

2.5 Control with Mouse 2.5.1 Connect Mouse It supports USB mouse through the ports on the rear panel. If mouse is not detected or doesn't work,

3 Basic Function Instruction 3.1 Startup and Shutdown Please make sure all the connections are done properly before you power on the unit. Proper

Fig 3-1 Login Notice: The default user name and password is “admin” and 123456”. For complete operational steps for changing password, adding or d

3.4 Live Playback Click Play button to playback the record. Refer to Figure 3-3. You can do complete operation by clicking the butto

4 Add IP Cameras This chapter mainly introduces how to connect multiple IP cameras through NVR. Once you finish adding IP cameras, you can see

same network segment. For example: If the IP address of NVR is 192.168.013.057, the IP address of IP camera must be 192.168.013.XXX. Step 3: Choo

5 Main Menu Setup Guide Click right mouse or press ESC/Stop button on the front panel to display the main menu toolbar on the bottom of the scr

PROVISION-ISR NVR-4100 User Manual 4CH 720P Real-Time Conventional NVR For H.264 4-channel network video recorder All rights reserved

Fig 5-2 Main Menu System Setup 5.1 Basic Configuration Basic configuration includes three sub menus: system, date & time and DST. 5.1.1 Syst

would help the user to recognize the device remotely. Device ID: This ID is used to map the NVR with IR remote controller and speed

Fig 5-5 Basic Configuration-DST Step 2: In this interface, enable daylight saving time, time offset, mode, start & end month/week/date, etc. S

Step 2: In this interface, you can adjust brightness, hue, saturation and contrast in live. Click “OK” button to save the setting. 5.2.2

Fig 5-8 Live Configuration-Mask Step 2: Click Setting button to go into live image. Step 3: Press and drag the left mouse button to set mask

Fig 5-10 Record Configuration-Record 5.3.2 Record Bitrate Step 1: Enter into MenuSetupRecord Record Bitrate. Refer to Fig 5-11: Step 2: Set

If the value of the parameter is set to exceed the maximum resources of the system, the system will automatically adjust it. 5.3.3 Time Step 1: En

Fig 5-13 Record Configuration-Stamp Step 2: Checkmark camera name and time stamp. Click Setting button to set up the position of the stamp. You ca

5.4.1 Schedule This tab allows defining schedule for normal recording for seven days of a week, 24 hours of a day. Every row denotes an hourly timel

Step 1: Enter into MenuSetupSchedule Motion tab. Step 2: The setup steps for schedule for motion based recording are similar to normal schedule s

CAUTION  Read this user manual carefully and use the device correctly and safely.  NVR warranty requires an intact serial number located on the bo

Step 5: Enter into Alarm Handling tab. Refer to Fig 5-17. Select hold time and then click “Setting” button to pop up a dialog box as shown in Fig 5-

If you have set schedule for sensor based recording in the same timeline, recordings can also be triggered. 5.5.2 Motion Alarm Motion includes two

higher the value is the more sensitive it is to motion. Since the sensitivity is influenced by color and time (day or night), you can adjust its val

To set up alarm out: Step 1: Enter into MenuSetupAlarm Out. Refer to Fig 5-22: Fig 5-22 System Configuration-Alarm Out Step 2: Input relay na

Fig 5-23 Network Configuration-Network Step 2: Set HTTP port. The default HTTP port is 80. If the value is changed, you shall add the port number w

Fig 5-24 Network Configuration-Email

Fig 5-26 Network Configuration-Other Settings Step 1: Enable DDNS server. Step 2: Select DDNS server. Step 3: Enter user name, password and host d

2) Fill in the registration form, then click "Submit" 3) Fill in the host name you want to apply for and press "Reques

(b) Setting up your DVR to work with the DDNS server 1) The DDNS server will work only if the three steps are completed; (1) domain registration,

5.7 User Management Configuration This tab allows you to add normal or advanced users. To add user and setup user authority: Step 1: Enter into Menu

Contents 1 Introduction ...

Fig 5-29 Add User-Authority To delete user: Step 1: Enter into MenuSetupUsers interface. Step 2: Select the added user you want to delete an

5.8.3 Block/Allow List Fig 5-30 Block/Allow List Here authorized user can prohibit computer users within a certain IP address range from accessin

6 Search, Playback & Backup Search configuration includes four submenus: time search, event search, file management and image. 6.1 Time Sear

Fig 6-2 Search Configuration-Event Search Step 2: Select date and channels on the right hand side. A data with highlighted borderline indicates pr

deleted or covered. Unlock: Select a locked file and click “Lock” button to unlock this file Delete: Select an unlocked file and click “Delete” butt

Fig 6-5 Backup Configuration Step 3: Select a required file or checkmark “All” to select all data files. Click Backup button to display Backup

7 Manage NVR 7.1 Check System Information Check system information includes six submenus: system, event, log, network, online user and record. 7.

7.3 Disk Management 1. Format the disk Step1: Enter into disk management tab. Note: please format the hard disk before recording. If formatted, it

8 Remote Surveillance 8.1 IE Remote Surveillance In order to view the NVR from a network, it must be connected to a LAN/WAN or internet. The networ

(user can enter into Main menuInformationNetwork interface to check IP address). Step 3: If users want to utilize dynamic domain name, please appl

5.5.3 Other Alarm ... 26 5.5.4 A

Step 2: Enter into Network interface and then click “Ethernet Connected” to check the internet connection of Apple PC. Step 3: After acqu

Input the name and password of Apple PC and then click “OK” to install this Active X control. Step 6: After finishing installing the Active X contro

1 Channel indicator 2 Screen display mode 3 Volume 4 Start IE record 5 Snap 6 Start talking 7 Start recording 8 Playback 9 Master/sub stream statu

dome. Click button near 'Iris' button to decrease light of the dome. 'Zoom' button. Click button near 'Zoom&ap

Fig 8-3 Play Record File Interface This NVR supports remote time search, event search and file management. By Time Search: Step 1: Enter into S

Fig 8-5 Time Search Playback By Event Search: Step 1: Enter into SearchEvent Search. Refer to Fig 8-6: Fig 8-6 Event Search Interface Step 2:

Fig 8-7 File Management Interface Lock: Select certain file item in the file list box and then click “Lock” button to lock this file that ca not b

as Fig 8-9: Fig 8-9 Remote System Configuration The sub menu list and the options in every menu are similar to that of the NVR. Please refer to Ma

8.8 By Phones with iPhone OS  Install through Iphone. Step 1: Open App Store software as shown in the figure on the left. Step2: Search “Pro

 "Provision Cam" Instruction 1. Login Step 1: Choose network type. There are two network connection ways: 3G/3G +WIFI, well video

8.8 By Phones with iPhone OS ... 52 8.9 By Phones with Android ...

：Screen mode button. You can choose 1，4，6，8，9，13 or 16 screen display mode. ：Favorite channel display button. If you save your favorite channel in t

all devices. Then you can click “Restore” button to restore all device information after you re-install the client or delete the devic

Fig 4 Fig 5 5. CMS Function This function makes multi-device managements and preview come

Step 2: Return to the main interface and click button to play the favorite channels.  Favorite groups of CMS Enable CMS function and e

8.9 By Phones with Android Software Installation Step 1: Run “Play Store” (or Google market) program. Step 2: Search “Provision Cam”. St

Record Playback: Click “Playback” in the main menu interface to enter playback interface. Then choose the channel you want

Settings: In the main menu interface, click “Settings” to enter the settings interface where you can configure local settings. Click “Local” to e

Appendix A FAQ Q1. The NVR fails to turn on even after connecting to the power, why? a. The power adapter could have gone bad. Please change a n

try restarting the NVR. c. The mouse may be incompatible or faulty. Please change a mouse. Q8. ActiveX control cannot be downloaded. How can I do? a

digital keys on the remote controller. Q11: A hard disk is being identified as a new device however it was being used with another NVR of same mo

1 Introduction 1.1 NVR Introduction This is a standard 4 CH real-time 1080P/720P/D1 high resolution NVR, which adopts the most advanced

files are saved in DVR format, you must have already downloaded the backup player box before doing backup. Then double click to open your USB disk t

Appendix B Calculate Recording Capacity You can calculate the size of hard disk according to the storage time and NVR recording s

Appendix C Compatible Devices 1. Compatible USB drive after test. Brand Capacity SSK 512MB, 1G, 2GB Netac 4GB Kingston 2GB Aigo 2GB Smatter

Appendix D: NVR Specifications Model/Specifications NVR-4100 Format ONVIF NVR Number of Channels (PoE) 4 (No) Playback Channels (remote) 4 (4) Liv

Notes:

SECURITY  Customize user right: log search, system setup, two way audio, file management, disk management, remote login, live view, manual record,

2 Hardware Installation Check the unit and the accessories after getting the device. Please don’t power up the unit till the physical installation
